Summary
In this lesson, students learn about the surprising results of the double slit experiment showing that particles have wavelike behavior through watching a Dr. Quantum video and through the PhET Quantum Wave Interference simulation. Students are split into groups to watch curated videos and create slideshow presentations to present either Wave-Particle Duality, De Broglie Wavelength, Heisenberg Uncertainty Principle, or Fourier Transformation. Students take notes that summarize the concepts presented that they could use while answering reflection questions at the end of the lesson.
Essential Question(s)
Is light a wave or a particle?
Snapshot
Engage
Students make observations and form questions over the Double Slit Experiment by viewing a video about it.
Explore
Students complete a simulation about quantum wave interference.
Explain
Students work in pairs to create a presentation about quantum phenomenon and then present their findings to the class. As students present, the other students take notes over the key concepts.
Extend
Students complete a simulation to reinforce how the Fourier Transformation helps explain the Heisenberg Uncertainty Principle. To shrink the range of positions of a wave packet, the uncertainty in momentum of the packet must increase.
Evaluate
Students respond to reflection questions about the lesson content while using the notes they have taken previously.
Materials
Lesson Slides (attached)
Is it a Wave or a Particle Teacher Guide (attached)
Quantum Wave Interference Simulation handout (attached, 1 per group of 2 students)
Quantum Wave Interference Simulation Teacher Guide (attached)
Presentation Note Catcher (attached, 1 per student)
Presentation Summary Teacher Guide (attached)
Fourier Making Waves Simulation handout (attached, 1 per group of 2 students)
Fourier Making Waves Simulation Teacher Guide (attached)
Exit Ticket Teacher Guide (attached)
Student devices with internet access (1 per group of 2 students)
Notebook paper
Pencil
Engage
30 Minute(s)
Use the attached Lesson Slides to guide the lesson. Display slides 3 and 4 to review the essential questions and learning objectives with students. Have students take out a piece of notebook paper. Move to slide 5 and Introduce the I Notice, I Wonder strategy to students. Move to slide 6 and watch the Dr. Quantum - Double Slit Experiment video. Give students 3-4 minutes to individually write down two things they noticed and two things they wonder about from the video.
Move to slide 7 and go over the three questions with the students. Go back and watch the video on slide 6 a second time. After the video is over, go back to slide 7 and have the students use their notes individually from the I Notice/I Wonder table for 3-4 minutes to answer the questions.
Have a class discussion to share answers to the questions. See the attached Is it a Wave or a Particle Teacher Guide for a list with timestamps of the ideas covered in the video. If any of the parts are not brought up by the students, cue the video to that section because students will reproduce the results in the next section. Students do not need to have any explanations at this point. They need to understand the experiments and what unpredicted results were observed from each one.
Explore
30 Minute(s)
Have students break into groups of 2 with a laptop and pass out the attached Quantum Wave Interference Simulation handout to each pair of students. Have students access the activity at https://phet.colorado.edu/en/simulation/quantum-wave-interference. The website is also on the handout for students. Display slides 8-10 to help guide them to the simulation, and have each group fill out their handout as the group spends 20 minutes working through the simulation.
Display slide 11 and use the What Did I Learn Today? strategy to have the students spend 5 minutes individually doing a free-write over what they learned and answer the question to show where they are at this point in the lesson.
Explain
100 Minute(s)
Display slide 12 and have the students access the Wakelet. Display slides 13-14 to go over the presentation requirements with the students. Have students pair up into groups of two to view their assigned videos and take notes, then create a slideshow presentation. Approximately one class period is needed for students to view the videos and create their slideshow presentation.
The next time class meets, pass out the attached Presentation Note Catcher to each student. Have each group present their slideshow while the rest of students take notes. Tell students that at the end of the lesson, the note catcher can be used to answer reflection questions about the lesson content.
See the attached Presentation Summary Teacher Guide for the presentation directions as well as explanations of the content that is included in each of the videos students will present. This information is helpful when assessing the student created presentations.
Extend
30 Minute(s)
Have students break into groups of two with a laptop and pass out the attached Fourier Making Waves Simulation handout to each pair of students. Have students access the activity at https://phet.colorado.edu/en/simulations/fourier-making-waves/about. The website is also on the handout. Display slides 15-16 to help guide students to set up the simulation and explore how the simulation works. Display slides 17-18, and have the students spend about 10 minutes playing the wave game. Display slide 19 to guide students back to the first part of the simulation, and have them work through the rest of the handout.
The Fourier Making Waves Simulation Teacher Guide is attached with explanations for the simulation.
Display slide 20 and have the students use the Point of Most Significance strategy to reflect on what was learned from the simulation.
Evaluate
25 Minute(s)
Display slides 21-25, and have students use the Bell Ringers and Exit Ticket instructional strategy to evaluate student understanding for the unit by having them answer the questions on the slides by using notebook paper. Encourage students to use their notes from the Presentation Note Catcher.
Refer to the attached Exit Ticket Teacher Guide for possible responses to the questions.
